DS530
  • 800 x 480P resolution and wide screen viewing angle enable clear and intuitive screen display;
  • 233PPS report rate ensures instant capture of every pen movement without any lagging;
  • 2048 levels of pressure sensitivity enable users to get different lines as the pressure applied varies, therefore capturing more biometric information during the signing process;
  • The battery-free EMR digital pen does not require charging or ink, bringing great flexibility;
  • Owning strong compatibility, DS530 helps users sign the files in Word, Excel, PDF, and other formats and on the web pages of major browsers.

Specifications

  • Model
    DS530
  • Pen Technology
    Electromagnetic Resonance
  • Color
    Charcoal grey
  • Pen Resolution
    5080LPI
  • Viewing Angle
    70°/70°(H)/50°/70°(V) (Typ.)(CR>10)
  • Response Time
    10ms
  • Brightness
    400 cd/m²
  • Contrast Ratio
    800:1
  • Active Area
    108 x 64.8 mm
  • LCD Type
    TFT
  • Resolution
    800 x 480 (16:9)
  • Fingerprint
    No
  • Panel Size
    5inch
  • OS Support
    Windows 7 or later
  • Interface
    USB-C
  • Sensing Height
    10mm
  • Accuracy
    ±0.5mm (Center); ±3mm (Corner)
  • Report Rate
    233PPS
  • Pressure Sensitivity
    2048 Levels
  • Net Weight
    270g
  • Dimension
    166.9 x 173.35 x 18.31 mm
